Aircraft Cable & Wire Rope

1/2" Galvanized Super Swaged Cable

We have ½" Galvanized Super Swaged Cable. For a smoother, quieter and faster zip line ride. This 6X26 Cable boast a 35,210 pound tensile strength. It is made by swaging 9/16" Wire Rope down to 1/2". It will help lengthen the life of your zip pulleys with its smooth ride. Made in Korea so the quality is as fine as our 3/8" Galvanized Aircraft Cable.



SSC12…………………………$2.00 per foot



All 1/2" Super Swage Cable orders must be shipped by common carrier. Additional freight charges may be necessary if a lift-gate is needed for delivery.



For Larger Orders please call (800)845-5692 and we will be happy to assist you. If you require a length that is not shown on the drop-down list below please call or Contact Us.



Choose Length
Choose Length

3/8" Galvanized Aircraft Cable (GAC)

Hot Dip Galvanized

Because of strength and flexibility this is the most widely used cable on the majority of ropes courses. Both High and Low courses.

Construction: 7X19

Tensile Strength: 14,400 lbs.

Diameter: 3/8"

Made in Korea

Due to the weight of 3/8" GAC, 750' & 1,000' spools must ship by a freight carrier since they are too heavy for UPS. Additional Fees may be charged if lift-gate is necessary for delivery.



Choose Length

3/8" Stainless Steel Aircraft Cable (SSAC)

Type 304 Stainless Steel

When the natural elements are a concern, on your Ropes Course, we offer Stainless Steel Aircraft Cable.

Construction: 7X19

Tensile Strength: 12,000 lbs.

Diameter: 3/8"

Due to the weight of 3/8" GAC, 750' & 1,000' spools must ship by a freight carrier since they are too heavy for UPS. Additional Fees may be charged if lift-gate is necessary for delivery.

Choose Length

1/2" Galvanized IWRC

Galvanized Independent Wire Rope Core - IWRC

Hot Dip Galvanized

Slightly larger in diameter and a good bit stronger than 3/8" GAC, this wire rope is often used for zip-lines over 500' long and on canopy tours.

Diameter: 1/2"

Tensile Strength: 20,300 lbs.

Made in Korea

Due to the weight of 1/2" GIWRC additional shipping charges will be added if lift-gate is necessary for delivery. All 1/2" GIWRC spools must ship by a freight carrier since they are too heavy for UPS.

Choose Length

********* Wire Rope Clips & Thimbles **********

Standard Duty Thimble

Hot Dip Galvanized

A must when connecting cable to nut eye bolts or ovaleye bolts. Keeps the cable from flattening around the eye causing the cable to weaken. Also used in eyespliced ropes. *When using a guy thimble with cable, match thimble size to cable. When using with Multiline Rope use thimble one size smaller than rope diameter.

Made in China



Sizes: 1/4", 5/16", 3/8", 1/2", 5/8", 3/4", 7/8", 1-1/4" and 1-3/4"



Sizes

Heavy Duty Thimble

Hot Dip Galvanized

Usually only used on cable or wire rope. Match the thimble size to your cable diameter. We offer an open pattern of the 3/8" which is gapped to fit onto our nut eye bolts and ovaleye bolts. The steel is thick enough that they won't bend and twist like standard guy thimble sometimes do.

Made in China.



Choose: 1/4", 5/16",3/8", 1/2", 5/8" and 3/4" Closed Pattern or 3/8" Open Pattern



Sizes

Columbus McKinnon (CM) Drop Forged Wire Rope Clip

Hot Dip Galvanized

 Columbus McKinnon has been around for 140 years.

Here is a reasonable priced, American made wire rope clip.

 Wire Rope Clips are used to secure the end of wire rope when forming a loop; i.e., for wire rope turn-back. Clips are available in two configurations: mid-grip (double saddle) and single saddle. Each configuration is equally strong and effective, but care must be exercised for proper installation of single saddle clips.

  • Precision manufactured and galvanized to meet federal specifications (FF-C-450 Type 1 Class 1) on 1/4" and larger.
  • Drop forged base.
  • Chart Note: 1/8" through 5/8" packed 1 piece per poly bag. 3/4" & larger shipped assembled in factory packs and tagged.
  • Made in USA.



This clamp is used in conjunction with 1/4", 5/16", 3/8" GAC or 1/2" GIWRC respectively. Please install as shown in the Method of Application below.



Size: 1/4", 5/16", 3/8" or 1/2"

Sizes

Crosby Drop Forged Wire Rope Clip

******Genuine Crosby******

Hot Dip Galvanized

  • Each base has a Product Identification Code (PIC) for material traceability, the name Crosby or CG, and size forged into it.
  • Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 1/8"-7/8" sizes, and 90% for sizes 1" through 3-1/2".
  • Entire Clip is Galvanized to resist corrosive and rusting action.
  • Sizes 1/8" through 2-1/2" and 3" have forged bases.
  • All Clips are individually bagged or tagged with proper application instructions and warning information.
  • Clip sizes up through 1-1/2" have rolled threads.
  • Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
  • Look for the Red-U-Bolt®, your assurance of Genuine Crosby Clips.
  • Made in USA.



This clamp is used in conjunction with 1/4", 5/16", 3/8" GAC or 1/2" GIWRC respectively. Please install as shown in the Method of Application below.



Size: 1/4", 5/16", 3/8" or 1/2"



Choose Size

Chicago Hardware Drop Forged Wire Rope Clip

Hot Dip Galvanized

This clamp is used in conjunction with 1/4", 5/16", 3/8" GAC or 1/2" GIWRC respectively. Please install as shown in the Method of Application below.



Please Note: Due to the close proximity and size of the nuts, you cannot use an impact socket for the 3/8" Clamp. An impact socket will fit the other sizes.

Made in USA.



Size: 1/4", 5/16", 3/8" or 1/2"



Choose Size

Galvanized Drop Forged Wire Rope Clip (Import)

Hot Dip Galvanized

This clamp is used in conjunction with 1/4", 5/16", 3/8" GAC or 1/2" GIWRC respectively. Please install as shown in the Method of Application below.

Made in China.



Size: 1/4", 5/16", 3/8" or 1/2"

Sizes

Columbus McKinnon Mid-Grip Wire Rope Clip

Hot Dip Galvanized

  Columbus McKinnon has been around for 140 years.

The CM Mid-Grip is designed for applications in the scaffolding industry. The redesigned mid-grip features a hexagon bolt head that fits securely into a forged, hex-shaped socket that prevents spinning even after repeated use and re-torqueing. It has precise threading on the nut and bolt to ensure tight alignment. This design also allows for full arc wrench swing, making installation and retightening quick and easy.

  • Allows for full arc wrench swing for quicker installation, retightening and disassembly.
  • Saddles are made of forged steel for strength and wearability. Full assembly is mechanical galvanized per ASTM B695-04 Class 25 Type 1.
  • Size, manufacturer and trace code are clearly marked on the saddle for easy identification.
  • Meets or exceeds performance requirements of FF-C-450 specifications, Type III, Class 1 and will provide maximum holding strength.
  • Made in USA.



Sizes Available: 1/4", 5/16", 3/8" and 1/2".



Sizes

Crosby Fist Grip Wire Rope Clip

Hot Dip Galvanized

  • Based on the catalog breaking strength of wire rope, Crosby wire rope clips have an efficiency rating of 80% for 3/16"-7/8", and 90% for sizes 1" through 1-1/2".
  • Bolts are an integeral part of the saddle. Nuts can be installed in such a way as to enable the operator to swing the wrench in a full arc for fast installation.
  • All sizes have forged steel saddles.
  • All Clips are individually bagged or tagged with proper application instructions and warning information.
  • Meets or exceeds all requirements of ASME B30.26 including identification, ductility, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other critical performance requirements including fatigue life, impact properties and material traceability, not addressed by ASME B30.26.
  • Assembled with standard heavy hex nuts.
  • Fist Grip wire rope clips meet or exceed the performance requirements of Federal Specification FF-C-450 Type III, Class 1, except for those provisions required of the contractor. For additional information, click here.
  • Made in USA.



Sizes Available: 1/4", 5/16", 3/8" and 1/2".



Choose Size

Galvanized Fist Grip Wire Rope Clip (Import)

Hot Dip Galvanized

Also known as a double grip clip. The design allows the installer to turn their wrench freely since the other nut is on the opposite side. More important, when these clips are removed from your zip-line cable for adjustments they don't leave the horrible crimps in the cable that Drop Froged Wire Rope Clips do.

Made in China.



Size: 1/4", 5/16", 3/8" or 1/2"



Choose Size

Method Of Application

The correct way to attach wire rope clips is illustrated to the right.

  1. Apply the first clip one base width from the dead end of the wire rope. The base or saddle should bear on the line end of the rope - U-bolt on the short end. Tighten nuts firmly.
  2. Attach second clip as close to loop as possible. Tighten nuts but not firmly.
  3. Attach balance of clips spaced equally between first two clips. Tighten all nuts completely. Apply initial load - inspect nuts and retighten. Inspect all clips periodically.



Clip Size / Minimum / Amount of / Torque

                Number     Cable to      in Ft. Lbs.

                of Clips      Turn Back

1/4"           2              4-3/4"          15

5/16"         2              5-1/4"          30

3/8"           2              6-1/2"          45

1/2"           3              11-1/2"        65
